FUTURA 24
from 155 to 210 HP
FUTURA 24
from 155 to 210 HP
Special snow ploughs to more sectors and moldboard monolithic steel with special cushioning system with springs and linkages. Suitable for use in urban and suburban presence of many obstacles.
Technical Data Sheet
Download Catalogue Sheetrelevant features
BLADE MICRO ALLOYED STEEL MADE HIGH YIELD STRENX 700/S700MC
SAFETY ON THE DOWN MODULAR ELEMENTS WITH COMPRESSION SPRINGS
HYDRAULIC CONTROL RIGHT-LEFT ROTATION WITH BY PASS SAFETY VALVE
HARDOX HB400 STEEL KNIVES
THREE POINT HITCH CAT. II
SIGNAL FLAGS
strong points
Hydraulic control right-left rotation with by pass safety valve
Safety knife with adjustable compression springs
technical data
- Machine
- BLADE MICRO ALLOYED STEEL MADE HIGH YIELD STRENX 700/S700MC
- Standard
- SIGNAL FLAGS
- Standard
- SWING SIDE
- Standard
- SET UP (RIGHT OR BENT SPECIFY WHEN ORDERING)
- Standard
- ADJUSTABLE SUPPORTING WHEELS
- Optional
- SLIDING SKATES
- Optional
- SET OF LED CLEARANCE LIGHTS WITH SUPPORTS
- Optional
- SET OF AUXILIARY LIGHTS COMPLETED WITH GALVANIZED SUPPORT AND DIRECTION INDICATORS
- Optional
- RUBBER SPLASH GUARD
- Optional
- FRENCH SIGNALLING KIT
- Optional
- GERMAN SIGNALING KIT
- Optional
- POLYURETHANE LATERAL EDGES
- Optional
- Safeties
- SAFETY ON THE DOWN MODULAR ELEMENTS WITH COMPRESSION SPRINGS
- Standard
- SIDE BUMPERS
- Standard
- SECTORS CM 40 -80 -120 SPECIFY WHEN ORDERING
- Standard
- Hydraulic system
- HYDRAULIC CONTROL RIGHT-LEFT ROTATION WITH BY PASS SAFETY VALVE
- Standard
- KIT ACCUMULATOR WEIGHT (NOT COMPATIBLE WITH THE BASIC VERSION WITH 3-POINT ATTACHMENT)
- Optional
- ) ELECTRO-HYDRAULIC UNIT EP5-H COMPLETE PANEL WITH CONTROL BOX IN THE CAB SOCKET + PLUG WIRE AND ELECTRICAL CABLE
- Optional
- Scraping Knives
- HARDOX HB400 STEEL KNIVES
- Standard
- SCRAPING POLIETILENE HD (PLASTIC) KNIFE REPLACING THE STEEL ONE
- Optional
- KOMBI BLADE STEEL AND RUBBER WITH AKUMINIUM OXIDE INSERTS REPLACING THE STEEL ONE
- Optional
- ATTACHMENT FOR TRACTOR
- THREE POINT HITCH CAT. II
- Standard
- DIN 76060 PLATE SIZE 3 (“B”) WITH PARALLELOGRAM LIFTING
- Optional
- DIN 76060 PLATE SIZE 5 (“A”) WITH PARALLELOGRAM LIFTING
- Optional
- SETRA PLATE WITH PARALLELOGRAM LIFTING
- Optional
- TERNA HOOK PLATE VERSION WITH FAKE PISTON TO COUPLE TO ARMS
- Optional
